Product specifications
Characteristic | Value |
|---|---|
| Model Code | M04080AB03AB020000AAF0000AA00F |
| Motor Series | 4000 Series |
| Valve system | Disc valve with valve drive |
| Orbital gearwheel set type | Geroler |
| Motor size | 130 |
| Geometric displacement [cm3/r [in3/r]] | 130.3 [7.95] |
| Motor type | Standard |
| Motor function | Standard |
| Mounting flange type | 4 Bolt - Square |
| Mounting flange dimension [pilot dia x height, bolt circle dia, hole [mm [inch]]] | 101.6 x 8.0, 127.0, 14.7 [4.00 x 0.32, 5.00, 0.58] SAE B |
| Shaft type | Splined |
| Shaft dimension | Dia. 1 1/4 inch, 14T, 3/8 - 16 UNC-2B thread in shaft end |
| Shaft Key | n/a |
| Main port thread type | UN / UNF |
| Main port style | Sideport - staggered |
| Main port dimension | 1 1/16 - 12 UN-2B SAE O-Ring port |
| Drain Port Dimension | 7/16 - 20 UNF-2B SAE O-Ring port |
| Brake Release Port Dimension | n/a |
| Painted | Yes |
| Paint information | Primer, Black, Low gloss |
| Special features hardware | Standard |
| Special Features Assembly | Standard |
| Dust seal | Standard |
| Shaft Seal | HNBR - High pressure |
| Seal Kit | 9901015-000 |
| Front bearing type | Tapered roller bearing |
| Rear bearing type | Tapered roller bearing |
| Orbital gearwheel set | Standard |
| Check valve function | Yes |
| Hydraulic valve function | None |
| Sensor | Speed sensor ready, 30 pulses |
| Packaging | Single pack |
| Name Tag | Danfoss name tag |
| Design Code | 06 |
| Accessories | Ssr 30p |
| CUSTOMER IDENTIFICATION | None |
| Case flow options | 7/16-20 check valve |
| Design code | Sixth |
| Displacement | 130.3 cm3/r [7.95 in3/r] |
| Geroler options | Standard |
| Low pressure relief | None |
| Low pressure relief | None |
| MOUNTING TYPE | 4 s p102 b127 h15 |
| Mounting type | 4 s p102 b127 h15 |
| Output shaft type | Spl 14t 12/24 3/8-16 sp38 |
| Output shaft type | Spl 14t 12/24 3/8-16 sp38 |
| Paint packaging | Black, individual box |
| Port Type | Sta 1 1/16-12 |
| Pressure flow option | None |
| Product | Motor |
| Product View (Switch) | Global (Standard) |
| Seal options | Hp shaft seal |
| Seal options | Hp shaft seal |
| Series | 4000 series |
| Series | 4000 series |
| Special assembly instructions | None |
