Product specifications
Characteristic | Value |
|---|---|
| Angle shape | Straight |
| Brand | Danfoss |
| Catalog Item | 3151X2Z |
| End size 1 | -2 |
| End Type 1 | Male pipe (NPTF) |
| Finish plating | Nickel plating |
| Item type | Adapter-plug |
| Product height in | 0.380 |
| Product height mm | 9.650 |
| Product length in | 0.579 |
| Product length mm | 14.700 |
| Product material | Brass |
| Product serial name | 3151 |
| Product width in | 0.380 |
| Product width mm | 9.650 |
| Thread sealant | Yes |
| Thread size 1 | 1/8-27 NPTF |
| Working temp max C | 121 |
| Working temp max F | 250 |
| Working temp min C | -54 |
| Working temp min F | -65 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 725975737019 |
