Product specifications
Characteristic | Value |
|---|---|
| Angle shape | 90 Degree |
| Brand | Weatherhead by Danfoss |
| Catalog Item | 65X8-BG |
| Drop dimension IN | 0.940 |
| Drop dimension MM | 23.90 |
| End type 2 | Line/hose/tube |
| Hex size 1 IN | 0.720 |
| Hex size 1 MM | 18.300 |
| Hex size 2 IN | 0.810 |
| Hex size 2 MM | 20.600 |
| Item type | Adapter-elbow |
| Product material | Brass |
| Thread sealant | No |
| Tube outside diameter 1 IN | 0.520 |
| Tube outside diameter 1 MM | 13.200 |
| Tube outside diameter 2 IN | 0.520 |
| Tube outside diameter 2 MM | 13.200 |
| Working pressure bar | 138.00 |
| Working pressure PSI | 2000.00 |
| Working temp max C | 121 |
| Working temp max F | 250 |
| Working temp min C | -54 |
| Working temp min F | -65 |
