Product specifications
Characteristic | Value |
|---|---|
| Brand | Danfoss |
| End type 1 | Female pipe (NPTF) |
| End type 2 | Female pipe (NPTF) |
| Hex size 1 IN | 0.810 |
| Hex size 1 MM | 20.600 |
| Product height in | 3.880 |
| Product height mm | 98.552 |
| Product length in | 3.020 |
| Product length mm | 76.708 |
| Product material | Brass |
| Product width in | 1.930 |
| Product width mm | 49.022 |
| Thread sealant | No |
| Tube outside diameter 1 IN | 0.313 |
| Tube outside diameter 1 MM | 7.900 |
| Tube outside diameter 2 IN | 0.313 |
| Tube outside diameter 2 MM | 7.900 |
| Working pressure bar | 2.00 |
| Working pressure PSI | 30 |
| Working temp max C | 121 |
| Working temp max F | 250 |
| Working temp min C | -54 |
| Working temp min F | -65 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 725975765210 |
