Product specifications

Characteristic
Value
Angle shapeStraight
Body size1/4
BrandDanfoss
CertificationsISO 6150 Series B
CompliancesA-A-59439
End size 1-6
End type 1Female BSPP port washer seal.
Finish platingAnodized
Hex size 1 IN1.260
Item typeFemale half
Latch typePush/pull
Product materialAluminum
Safety locking mechanismPush button
Seal materialNitrile (NBR)
Sub brandGromelle
Thread size 1G 3/8
Valve type1 way
Working pressure max psi232
Working temperature max F212
Working temperature min F-4
