Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 3.954 |
| A dimension MM | 100.600 |
| Angle shape | 45 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.800 |
| Construction Style | Reusable |
| Drop dimension IN | 0.994 |
| Drop dimension MM | 25.30 |
| End connection torque | 170-192 lb-ft(230-260 Nm) |
| End size 1 | -20 |
| End Type 1 | Female BSPP swivel |
| Finish plating | Dura-Kote |
| Hex size 1 IN | 1.969 |
| Hex size 1 MM | 50.000 |
| Hex size 2 IN | 1.417 |
| Hex size 2 MM | 36.000 |
| Hose cut off factor IN | 2.637 |
| Hose cut off factor MM | 67.100 |
| Hose size | -20 |
| Inside diameter IN | 0.983 |
| Inside diameter MM | 25.000 |
| Product height in | 2.690 |
| Product height mm | 68.326 |
| Product length in | 4.940 |
| Product length mm | 125.476 |
| Product material | Carbon steel |
| Product width in | 2.270 |
| Product width mm | 57.658 mm |
| Series | Socketless |
| Thread sealant | No |
| Thread size 1 | G 1 1/4 |
| Tube OD 1 IN | 1.181 |
| Tube OD 1 MM | 30.000 |
| Working pressure max bar | 172 |
| Working pressure max psi | 2500 |
| Working temperature max C | 121 |
| Working temperature max F | 250 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
