Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.516 |
| A dimension MM | 38.510 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.310 |
| Compatible hose ID MM | 7.900 |
| Construction Style | Reusable |
| End connection torque | 18-20 lb-ft(24-27 Nm) |
| End size 1 | -6 |
| End type 1 | Female 37 degree swivel |
| Hose size | -6 |
| Inside diameter IN | 0.294 |
| Inside diameter MM | 7.470 |
| Product height in | 0.490 |
| Product height mm | 12.446 |
| Product length in | 1.520 |
| Product length mm | 38.608 |
| Product material | Brass |
| Product width in | 0.490 |
| Product width mm | 12.446 mm |
| Series | 100R5 Reusable |
| Working pressure max BAR | 483 |
| Working pressure max PSI | 7100 |
| Working temperature max C | 121 |
| Working temperature max F | 250 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
