Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.080 |
| A dimension MM | 53.000 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.380 |
| Compatible hose ID MM | 9.500 |
| Construction Style | Crimp |
| End Type 1 | Millimetrique standpipe |
| End size 1 | -10 |
| Finish plating | Protective oil |
| Hose cut off factor IN | 1.180 |
| Hose cut off factor MM | 30.000 |
| Hose size | -6 |
| Inside diameter IN | 0.2900 |
| Inside diameter MM | 7.5000 |
| Product height in | 0.591 |
| Product height mm | 15.000 |
| Product length in | 2.087 |
| Product length mm | 53.000 |
| Product material | Carbon steel |
| Product width in | 0.591 |
| Product width mm | 15.000 mm |
| Series | Socketless |
| Thread sealant | No |
| Tube OD 1 IN | 0.393 |
| Tube OD 1 MM | 10.000 |
| Working pressure max BAR | 400 |
| Working pressure max PSI | 5800 |
