Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.340 |
| A dimension MM | 34.000 |
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 0.500 |
| Compatible hose ID MM | 12.700 |
| Compatible hoses | EC110 |
| Construction Style | Crimp |
| Hose cut off factor MM | 45.000 |
| Hose size | -8 |
| Inside diameter IN | 0.730 |
| Inside diameter MM | 18.600 |
| Product height in | 1.102 |
| Product height mm | 28.000 |
| Product length in | 1.339 |
| Product length mm | 34.000 |
| Product material | 304 Stainless steel |
| Product width in | 1.102 |
| Product width mm | 28.001 mm |
| Series | Winner 2-Piece |
| Thread sealant | No |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
