Product specifications
Characteristic | Value |
|---|---|
| A dimension MM | 145.500 |
| Angle shape | 90 Degree |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 0.500 |
| Compatible hose ID MM | 12.700 |
| Construction Style | Crimp |
| Drop dimension IN | 3.340 |
| Drop dimension MM | 85.00 |
| End size 1 | -8 |
| End type 1 | Female pipe swivel (NPSM) |
| Hex size 1 IN | 1.060 |
| Hex size 1 MM | 26.900 |
| Hose cut off factor IN | 3.600 |
| Hose cut off factor MM | 91.500 |
| Hose size | -8 |
| Inside diameter IN | 1.060 |
| Inside diameter MM | 27.000 |
| Product height in | 1.220 |
| Product height mm | 30.988 |
| Product length in | 2.380 |
| Product length mm | 60.452 |
| Product material | Carbon steel |
| Product width in | 1.060 |
| Product width mm | 26.924 mm |
| Thread sealant | No |
