Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.944 |
| A dimension MM | 74.800 |
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 0.880 |
| Compatible hose ID MM | 22.225 |
| Compatible hoses | EC110EC210FC687GH781GH793FC686GH663 |
| Construction Style | Crimp |
| End size 1 | -16 |
| End type 1 | Female ORFS swivel |
| Finish plating | Zinc plating |
| Hex size 1 IN | 1.614 |
| Hex size 1 MM | 41.000 |
| Hex size 2 IN | 1.614 |
| Hex size 2 MM | 40.996 |
| Hose cut off factor IN | 1.370 |
| Hose cut off factor MM | 34.800 |
| Hose size | -14 |
| Inside diameter IN | 0.7080 |
| Inside diameter MM | 18.0000 |
| Product height in | 1.860 |
| Product height mm | 47.244 |
| Product length in | 3.527 |
| Product length mm | 89.586 |
| Product material | Carbon steel |
| Product width in | 1.614 |
| Product width mm | 40.996 mm |
| Thread sealant | No |
| Thread size 1 | 1 7/16-12 UN |
| Working pressure max bar | 414 |
| Working pressure max psi | 6000 |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
