Product specifications
Characteristic | Value |
|---|---|
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 0.625 |
| Compatible hose ID MM | 15.875 |
| Construction Style | Crimp |
| End size 1 | -16 |
| End Type 1 | Female ORFS swivel |
| Hex size 1 IN | 1.060 |
| Hex size 1 MM | 26.900 |
| Hex size 2 IN | 1.180 |
| Hex size 2 MM | 30.000 |
| Hose cut off factor IN | 1.870 |
| Hose cut off factor MM | 47.498 |
| Hose size | -10 |
| Inside diameter IN | 0.4500 |
| Inside diameter MM | 11.4300 |
| Product height in | 1.360 |
| Product height mm | 34.544 |
| Product length in | 3.661 |
| Product length mm | 92.989 |
| Product material | Carbon steel |
| Product width in | 1.181 |
| Product width mm | 29.997 mm |
| Thread sealant | No |
