Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 6.940 |
| A dimension MM | 176.500 |
| Angle shape | 45 Degree |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 1.500 |
| Construction Style | Crimp |
| Drop dimension IN | 1.480 |
| Drop dimension MM | 37.70 |
| End size 1 | -24 |
| End Type 1 | Female ORFS swivel |
| Finish plating | Zinc plating |
| Hose cut off factor IN | 4.271 |
| Hose cut off factor MM | 108.500 |
| Inside diameter IN | 1.259 |
| Inside diameter MM | 32.000 |
| Product height in | 3.248 |
| Product height mm | 82.499 |
| Product length in | 8.712 |
| Product length mm | 221.285 |
| Product material | Carbon steel |
| Product width in | 2.362 |
| Product width mm | 59.995 mm |
| Thread sealant | No |
| Working pressure max bar | 276 |
| Working pressure max psi | 4000 |
General specifications
Characteristic | Value |
|---|---|
| Proposition 65 | Cancer and Reproductive Harm |
