Product specifications
Characteristic | Value |
---|---|
A dimension IN | 2.468 |
A dimension MM | 62.700 |
Angle shape | Straight |
Brand | Winner Duffield by Danfoss |
Compatible hose ID IN | 0.250 |
Compatible hose ID MM | 6.350 |
Construction Style | Reusable |
End size 1 | -6 |
End size 2 | -4 |
End type 1 | Male 37 degree |
End type 2 | Line/hose/tube |
Finish plating | Zinc plating |
Hex size 1 IN | 0.669 |
Hex size 1 MM | 17.000 |
Hose cut off factor IN | 0.868 |
Hose cut off factor MM | 22.060 |
Hose size | -4 |
Inside diameter IN | 0.171 |
Inside diameter MM | 4.360 |
Product material | Carbon steel |
Thread sealant | No |
Thread size 1 | 9/16-18 UNF |
