Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 6.200 |
| A dimension MM | 157.500 |
| Angle shape | 90 Degree |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.750 |
| Construction Style | Crimp |
| Drop dimension IN | 3.937 |
| Drop dimension MM | 100.00 |
| End size 1 | -20 |
| End type 1 | Female ORFS swivel |
| Finish plating | Zinc plating |
| Hex size 2 IN | 1.970 |
| Hex size 2 MM | 50.038 |
| Hose cut off factor IN | 3.763 |
| Hose cut off factor MM | 95.600 |
| Hose size | -20 |
| Inside diameter IN | 0.9840 |
| Inside diameter MM | 25.0000 |
| Product height in | 5.295 |
| Product height mm | 134.493 |
| Product length in | 7.185 |
| Product length mm | 182.499 |
| Product material | Carbon steel |
| Product width in | 1.968 |
| Product width mm | 49.987 mm |
| Thread sealant | No |
| Working pressure max bar | 310 |
| Working pressure max psi | 4500 |
