Product specifications
Characteristic | Value |
|---|---|
| Bend radius min (inch) | 12.000 |
| Bend radius min (mm) | 304.800 |
| Brand | Boston by Danfoss |
| Burst pressure (bar) | 431 |
| Burst pressure (psi) | 6250 |
| Color | Blue |
| Conductivity | Conductive |
| Construction | 1 Ply braid |
| Cover material | Thermoplastic |
| Inside diameter (inch) | 1.26 |
| Inside diameter (mm) | 32.00 |
| Outside diameter (inch) | 1.78 |
| Outside diameter (mm) | 45.21 |
| Package form | Bulk |
| Reinforcement material | Fabric |
| Series | FC701 Gator |
| Size | -20 |
| Tube material | Thermoplastic |
| Working pressure max (bar) | 172 |
| Working pressure max (psi) | 2500 |
| Working temperature max (C) | 66 |
| Working temperature max (F) | 150.0 |
| Working temperature min (C) | -40 |
| Working temperature min (F) | -40.0 |
