Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.468 |
| A dimension MM | 62.687 |
| Angle shape | Straight |
| Brand | Synflex by Danfoss |
| Catalog Item | 4S24FH24 |
| Compatible hose ID IN | 0.380 |
| Compatible hose ID MM | 9.500 |
| Construction Style | Swage |
| End size 1 | -6 |
| End type 1 | Male ORFS |
| Finish plating | Zinc plating |
| Hex size 1 IN | 0.750 |
| Hex size 1 MM | 19.050 |
| Hex size 2 IN | 0.750 |
| Hex size 2 MM | 19.000 |
| Hose cut off factor IN | 1.218 |
| Hose cut off factor MM | 30.937 |
| Hose size | -6 |
| Inside diameter IN | 0.264 |
| Inside diameter MM | 6.706 |
| Product material | Carbon steel |
| Series | 903 |
| Thread sealant | No |
| Working pressure max BAR | 621 |
| Working pressure max PSI | 9100 |
