HOSE FTG,SW/08,JIC-F/08,CS,STR

90308-085540-0

Catalog item:

90308-085540-0

This product has been discontinued and is no longer available. At this time, there is no direct replacement product.

The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.

If you're looking for a similar product, you can check out other options within the same product type by visiting the product type page.: Thermoplastic fittings, Thermoplastic hydraulic fittings

Tools

Characteristic	Value
A dimension IN	3.270
A dimension MM	83.260
Angle shape	45 Degree
Backup hex size IN	0.880
Backup hex size MM	22.400
Brand	Synflex by Danfoss
Catalog Item	90308-085540-0
Compatible hose ID IN	0.500
Compatible hose ID MM	12.700
Compatible hoses	25CT30CT (Size dependent)31303440 (Size dependent)35803630 (Size dependent)3740 (Size dependent)37AL3800 (Size dependent)3R30
Construction Style	Swage
Drop dimension IN	0.710
Drop dimension MM	18.11
End connection hex size IN	0.880
End connection hex size MM	22.400
End connection torque	35-46 lb-ft(47-62 Nm)
End size 1	-12
End type 1	Female 37 degree swivel
Finish plating	Zinc plating
Hose cut off factor IN	1.810
Hose cut off factor MM	45.974
Hose size	-8
Inside diameter IN	0.390
Inside diameter MM	9.906
Product height in	0.710
Product height mm	18.034
Product length in	3.270
Product length mm	83.058
Product material	Carbon steel
Product width in	1.000
Product width mm	25.400
Series	903
Thread size 1	3/4-16 UNF

Characteristic	Value
EAN/UPC	639789325440
