Product specifications
Characteristic | Value | Description |
|---|---|---|
| Adjustment type | Stem | |
| Brand | Vickers by Danfoss | |
| Cavity | C-16-2 | |
| Factory set flow rate GPM | 10.000 | |
| Factory set flow rate LPM | 38.00 | |
| Flow rate GPM | 45.00 | |
| Flow rate LPM | 170.000 | |
| Fluid Compatibility | MIL-H-5606, SAE10, SAE20, etc | |
| Function | Manual Rotary Flow Control | |
| Housing | No | |
| Installation type | Screw-in Cartridge | |
| Leakage | 82 cc/min | |
| Maximum flow rate LPM | 20.00 | |
| Model Code 1 | MRV2-16-0-0-20 | |
| Number of housing ports | 2 | |
| Number of valve ports | 2 | |
| Operating temperature | -40 C to 120 C (-40 to 248 F) | |
| Port Type | Cartridge Only | |
| Pressure rating BAR | 210.000 | |
| Pressure rating PSI | 3000.000 | |
| Rec filtration level | 18/16/13 | |
| Seal Type | Buna-N | |
| Special features | None | |
| Spool seal | No | |
| Style | Spool | |
| Torque alu cavity | 108-122 Nm | |
| Torque steel cavity | 139-149 Nm |
