Product specifications
Characteristic | Value |
|---|---|
| Actuation option | None |
| Adjustment type | Leakproof Screw |
| Brand | Danfoss |
| Cavity | A5302 |
| Detent option | No |
| Flow rate lpm | 30.000 |
| Fluid Compatibility | MIL-H-5606, SAE10, SAE20, etc |
| Function | Pilot to shift valve |
| Housing | Yes |
| Housing material | Steel |
| Installation type | Screw-in Cartridge |
| Model Code | 1RDS352-2-P3W-6S-377 |
| Model Code 1 | 1RDS352-2-P-3W-6-S-377 |
| Number of housing ports | 4 |
| Number of valve ports | 4 |
| Operating temperature | -20 C to 90 C (-4 to194 F) |
| Operation | Pilot operated |
| Pilot pressure setting BAR | 65.00 |
| Port size | 3/8" |
| Port type | BSP |
| Pressure rating BAR | 350.00 |
| Recommended filtration level | 18/16/13 |
| Seal Type | Buna-N |
