Product specifications
Characteristic | Value | Description |
|---|---|---|
| Brand | Vickers by Danfoss | |
| Cavity | C-16-3S | |
| Coil series | EPV Series | |
| Coil termination | Deutsch Moulded | |
| Diode | No | |
| Flow rate GPM | 26.00 | |
| Flow rate LPM | 100.000 | |
| Fluid compatibility | MIL-H-5606, SAE10, SAE20, etc | |
| Function | Prop Flow Control | |
| Housing | Yes | |
| Housing material | Steel | |
| Installation type | Screw-in Cartridge | |
| Leakage | 50 cc/min | |
| Minimum working pressure BAR | 100.00 | |
| Minimum working pressure PSI | 1454.00 | |
| Model Code 1 | EPV16-A-10-S-10H-N-12D-S-N-13 | |
| Number of housing ports | 3 | |
| Number of valve ports | 3 | |
| Operating temperature | -30 C to 90 C (-22 to 194 F) | |
| Operation | Elecro Proportionally Ctrl | |
| Override type | Screw-in type | |
| Port Size | 5/8" | |
| Port Type | SAE | |
| Pressure ratiing PSI | 4000.000 | |
| Pressure rating BAR | 280.000 | |
| Recommended filtration level | 15/13/11 | |
| Seal type | Buna-N | |
| Special features | None | |
| Style | Poppet | |
| Torque into aluminium cavity | 108-122 Nm | |
| Torque into steel cavity | 136-149 Nm | |
| Voltage | 12 V | |
| Voltage type | DC | |
| Working pressure max bar | 280 | |
| Working pressure max psi | 4000 |
