Product specifications
Characteristic | Value | Description |
|---|---|---|
| Adjustment type | Internal | |
| Brand | Vickers by Danfoss | |
| Cavity | C-10-3 | |
| Factory set pressrue BAR | 10.000 | |
| Factory set pressrue PSI | 150.000 | |
| Flow rate GPM | 10.00 | |
| Flow rate LPM | 38.000 | |
| Fluid compatibility | MIL-H-5606, SAE10, SAE20, etc | |
| Function | Pressure Reducing/Relieving | |
| Housing | No | |
| Housing material | None | |
| Installation type | Screw-in Cartridge | |
| Leakage | 820 cc/min | |
| Max working pressure BAR | 20.000 | |
| Max working pressure PSI | 291.000 | |
| Min working pressure BAR | 4.000 | |
| Min working pressure PSI | 51.000 | |
| Model Code 1 | PRV2-10-I-0-3-1.5 | |
| Number of housing ports | 3 | |
| Number of valve ports | 3 | |
| Operating temperature | -40 C to 120 C (-40 to 248 F) | |
| Operation | Pilot operated | |
| Port size | None | |
| Port type | Cartridge Only | |
| Product height in | 1.000 | |
| Product height mm | 25.400 | |
| Product length in | 3.890 | |
| Product length mm | 98.806 | |
| Product width in | 1.000 | |
| Product width mm | 25.400 mm | |
| Recommended filtration level | 18/16/13 | |
| Seal type | Buna-N | |
| Special features | None | |
| Style | Spool |
