Product specifications
Characteristic | Value | Description |
|---|---|---|
| Actuation type | Manual lever operated | |
| Brand | Vickers by Danfoss | |
| Coil Rating | None | |
| Design series | 10 Series | |
| Electrical connection | None | |
| Flow rate upto GPM | 100.0 | |
| Flow rate upto LPM | 380.0 | |
| Fluid cleanliness | 19/17/14 micron | |
| Fluid compatibility | Petroleum oils | |
| Gauge port thread type | 0.4375 - 20 UNF, SAE Thread | |
| Indicator light | No | |
| Int pilot drain | External | |
| Interface | ISO4401-08 | |
| Manual override | None | |
| Model Code 1 | DG17V86N10 | |
| Performance | Standard performance | |
| Pressure rating BAR | 350 | |
| Pressure rating PSI | 5000 | |
| Product height in | 12.500 | |
| Product length in | 13.820 | |
| Product width in | 4.500 | |
| Seal type | Buna-N | |
| Solenoid Energising ID | None | |
| Special features | None | |
| Spool Position Monitor | No | |
| Spool type | Spool 6 | |
| Spring arrangement | No spring detented | |
| Stage | Single stage | |
| Surge Suppr Damper | No | |
| Tank port rating BAR | 350.0 | |
| Tank port rating PSI | 5000 | |
| Valve mount type | Subplate/manifold mounted | |
| Valve type | Directional control valve | |
| Working temp max C | 70 | |
| Working temp max F | 158 | |
| Working temp min C | -20 | |
| Working temp min F | -4 |
