Danfoss
71392-DAJ
This product has been discontinued and is no longer available. At this time, there is no direct replacement product.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
71392-DAJ
Product specifications
Characteristic | Value | Description |
|---|---|---|
| Application | Transit Mixer, Motor Grader | |
| Brand | Danfoss | |
| Control | No Control - Fixed Displacement | |
| Design code | C | |
| Displacement | 2.48 in³/rev | |
| Feature | Great price and performanceHighly customizableEasy to service | |
| Identification | Standard | |
| Main Ports | 1.0625-12 UN-2B SAE O-Ring Ports - Side | |
| Maximum Speed | 4500 RPM | |
| Minimum Displacement | 2.48 in³/rev | |
| Model Code | AAMGA210H000A0C | |
| Output Shaft | 13 Tooth 16/32 Spline, Shaft Extension 41.1 [1.62] | |
| Paint | Primer Per Spec 209-13A | |
| Product Height | 6.56 in | |
| Product Length/Depth | 10.6 in | |
| Product Type | Medium Duty Variable Motor | |
| Product Volume | 478.408 in³ | |
| Product Weight | 31 lb | |
| Product Width | 6.88 in | |
| Special features | None | |
| Sub-brand | None | |
| System Working Temperature | 225 °F | |
| Torque | 166.8 Nm | |
| Trade Name | 71392 Series | |
| Working pressure | 35000000 Pa |
