Synflex by Danfoss
9C416-14J005-0
This product has been discontinued and is no longer available. At this time, there is no direct replacement product.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
9C416-14J005-0
Product specifications
Characteristic | Value | Description |
|---|---|---|
| Angle (shape) | Straight | |
| Brand | Synflex by Danfoss | |
| Compatible hose ID | 1 in | |
| Construction style | Reusable | |
| End gender 1 | Male | |
| End type 2 | Line/Hose/Tube | |
| Feature | Dura-Kote plating for superior corrosion resistanceInnovative design to deliver performance and maximum uptimeSystem engineered to extend hose assembly life | |
| Hex Size 1 | 1.5 in | |
| Hex Size 2 | 2.13 in | |
| Hose cut-off factor | 5.3 in | |
| Hose dash size | -16 | |
| Inside diameter | .72 in | |
| Item type | Fitting Assembly | |
| Outside diameter | 2.05 in | |
| Product Height | 2.45 in | |
| Product Length/Depth | 10.03 in | |
| Product material | Stainless Steel | |
| Product Type | Crimp Hose Fittings | |
| Product Volume | 52.342 in³ | |
| Product Weight | 1.67 lb | |
| Product Width | 2.13 in | |
| Sub-brand | None | |
| Thread sealant | No | |
| Trade Name | 9C4 Series |
