Aeroquip by Danfoss
D9900-12
This product has been discontinued and is no longer available. At this time, there is no direct replacement product.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
D9900-12
Product specifications
Characteristic | Value | Description |
|---|---|---|
| Abrasion resistance | Standard | |
| Application | Hydraulics, crude fuel and lubricating oils, gasoline, water and phosphate eter base hydraulic fluids. | |
| Bend radius - min | 9.5 in | |
| Brand | Aeroquip by Danfoss | |
| Burst pressure | 12500 Psi | |
| Color | Black | |
| Construction | 2-ply braid | |
| Cover material | Elastomer | |
| Dash size | -12 | |
| Feature | Maximum durability under harsh operating conditionsRobust construction able to withstand highest pressuresSystem engineered to extend hose assembly life | |
| Inside diameter | .75 in | |
| Lay line style | Embossed | |
| Outside diameter | 1.16 in | |
| Product Height | 1.16 in | |
| Product Length/Depth | 1 ft | |
| Product Type | Rubber Hydraulic | |
| Product Volume | 16.147 in³ | |
| Product Weight | .67 lb | |
| Product Width | 1.16 in | |
| Reinforcement material | Wire | |
| Sub-brand | None | |
| Trade Name | D9900 Series | |
| Tube material | AQP Inner tube | |
| Tube wall thickness | .04 in | |
| Working pressure | 3125 Psi | |
| Working temperature - max | 250 °F | |
| Working temperature - min | -40 °F |
