Aeroquip by Danfoss
EC036-08RL
This product has been discontinued and is no longer available. At this time, there is no direct replacement product.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
EC036-08RL
Product specifications
Characteristic | Value | Description |
|---|---|---|
| Abrasion resistance | Standard | |
| Application | Gasoline, fuel and lubricating oils, air and water. | |
| Bend radius - min | 2 in | |
| Brand | Aeroquip by Danfoss | |
| Burst pressure | 1200 Psi | |
| Certification(s) | SAE J1402A | |
| Color | Black | |
| Conditional temperature range | -40 - 302 F, air not to exceed 250 F, water not to exceed 180 F | |
| Conductivity | Conductive | |
| Construction | 1 Ply Braid | |
| Cover material | Chlorinated Polyethylene | |
| Cover style | Perforated | |
| Dash size | -8 | |
| Feature | Longer hsoe assembly lifeWithstands high pressure and temperaturesKink resistant | |
| Inside diameter | .5 in | |
| Lay line style | Ink Jet | |
| Outside diameter | .78 in | |
| Package form | Reel | |
| Product Height | .78 in | |
| Product Length/Depth | 1 ft | |
| Product Type | Socketless Low Pressure Hose | |
| Product Volume | 7.301 in³ | |
| Product Weight | .22 lb | |
| Product Width | .78 in | |
| Reinforcement material | Polyester | |
| Sub-brand | None | |
| Trade Name | EC036 Series | |
| Tube material | Chlorinated Polyethylene | |
| Tube wall thickness | .14 in | |
| UPC | 678146071347 | |
| Working pressure | 300 Psi | |
| Working temperature - max | 212 °F | |
| Working temperature - min | -40 °F |
