Boston by Danfoss
EH912BU20-100
This product has been discontinued and is no longer available. At this time, there is no direct replacement product.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
EH912BU20-100
Product specifications
Characteristic | Value | Description |
|---|---|---|
| Abrasion resistance | Standard | |
| Application | Chemical transfer. | |
| Bend radius - min | 5.5 in | |
| Brand | Boston by Danfoss | |
| Burst pressure | 1000 Psi | |
| Color | Blue | |
| Conductivity | Conductive | |
| Construction | 2-ply braid | |
| Cover material | Synthetic Rubber | |
| Dash size | -20 | |
| Feature | A solution for every hose needIndustry leader since 1870Designed for safety and reliability | |
| Inside diameter | 1.25 in | |
| Lay line style | Ink Transfer | |
| Outside diameter | 1.79 in | |
| Product Height | 1 in | |
| Product Length/Depth | 100 ft | |
| Product Type | Industrial Hose | |
| Product Volume | 1200 in³ | |
| Product Weight | .55 lb | |
| Product Width | 1 in | |
| Reinforcement material | Fabric and Wire | |
| Sub-brand | None | |
| Trade Name | EH912 Series | |
| Tube material | Thermoplastic | |
| Tube wall thickness | 2.5 in | |
| Working pressure | 200 Psi | |
| Working temperature - max | 160 °F | |
| Working temperature - min | -45 °F |
