Boston by Danfoss
EHG003-16-M40
This product has been discontinued and is no longer available. At this time, there is no direct replacement product.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
EHG003-16-M40
Product specifications
Characteristic | Value | Description |
|---|---|---|
| Abrasion resistance | Standard | |
| Application | For suction and delivery of LPG. | |
| Bend radius - min | 5.91 in | |
| Brand | Boston by Danfoss | |
| Burst pressure | 1460 Psi | |
| Color | Black | |
| Conductivity | Conductive | |
| Construction | 2-ply braid | |
| Cover material | Synthetic Rubber | |
| Cover style | Pin-Pricked | |
| Dash size | -16 | |
| Feature | A solution for every hose needIndustry leader since 1870Designed for safety and reliability | |
| Inside diameter | 1 in | |
| Lay line style | Ink Transfer | |
| Outside diameter | 1.49 in | |
| Product Height | 1.49 in | |
| Product Length/Depth | 12.19 ft | |
| Product Type | Industrial Hose | |
| Product Volume | 324.756 in³ | |
| Product Weight | 1.9845 lb | |
| Product Width | 1.49 in | |
| Qualified hose fittings | Swaged or crimp male couplings | |
| Reinforcement material | High-tensile synthetic textile and steel helix wire | |
| Sub-brand | None | |
| Trade Name | EHG003 Series | |
| Tube material | Nitrile | |
| Tube wall thickness | 1.75 in | |
| Vacuum rating | 24 iHg | |
| Working pressure | 365 Psi | |
| Working temperature - max | 158 °F | |
| Working temperature - min | -22 °F |
