Boston by Danfoss
EHP522-48-100
This product has been discontinued.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
EHP522-48-100
Product specifications
Characteristic | Value | Description |
|---|---|---|
| Abrasion resistance | Standard | |
| Application | High pressure petroleum suction and discharge. | |
| Bend radius - min | 11.81 in | |
| Brand | Boston by Danfoss | |
| Burst pressure | 900 Psi | |
| Certification(s) | RMA Class A | |
| Color | Black | |
| Conductivity | Conductive | |
| Construction | Extruded | |
| Cover material | Synthetic Rubber | |
| Dash size | -48 | |
| Feature | A solution for every hose needIndustry leader since 1870Designed for safety and reliability | |
| Inside diameter | 3 in | |
| Lay line style | Ink Transfer | |
| Outside diameter | 3.62 in | |
| Product Height | 3.69 in | |
| Product Length/Depth | 100 ft | |
| Product Type | Industrial Hose | |
| Product Volume | 16339.32 in³ | |
| Product Weight | 219 lb | |
| Product Width | 3.69 in | |
| Qualified hose fittings | Cam and groove, Combination nipple | |
| Reinforcement material | High-tensile synthetic textile with helical wire and anti-static copper wire | |
| Sub-brand | None | |
| Trade Name | EHP522 Series | |
| Tube material | Synthetic Rubber | |
| Tube wall thickness | .31 in | |
| UPC | 639789348036 | |
| Vacuum rating | 25 iHg | |
| Working pressure | 300 Psi | |
| Working temperature - max | 158 °F | |
| Working temperature - min | -31 °F |
