Aeroquip by Danfoss
FC132-64
This product has been discontinued and is no longer available. At this time, there is no direct replacement product.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
FC132-64
Product specifications
Characteristic | Value | Description |
|---|---|---|
| Abrasion resistance | Standard | |
| Application | Fresh and salt water systems, oil applications and fuel systems. | |
| Bend radius - min | 30 in | |
| Brand | Aeroquip by Danfoss | |
| Burst pressure | 2400 Psi | |
| Color | Black | |
| Compliance(s) | MIL-H-24136/4 | |
| Conductivity | Conductive | |
| Construction | Multi Spiral | |
| Cover material | Synthetic Rubber | |
| Dash size | -64 | |
| Feature | Designed for safety and reliabilityWide range of styles, configurationsMaximum durability under harsh operating conditions | |
| Inside diameter | 4 in | |
| Lay line style | Embossed | |
| Outside diameter | 4.86 in | |
| Package form | Bulk | |
| Packaged Weight | 3.15 lb | |
| Product Height | 4.86 in | |
| Product Length/Depth | 1 ft | |
| Product Type | Marine Military | |
| Product Volume | 283.435 in³ | |
| Product Weight | 3.15 lb | |
| Product Width | 4.86 in | |
| Reinforcement material | Yarn | |
| Sub-brand | None | |
| Trade Name | FC132 Series | |
| Tube material | Synthetic Rubber | |
| Tube wall thickness | .5 in | |
| Working pressure | 600 Psi | |
| Working temperature - max | 200 °F | |
| Working temperature - min | -40 °F |
