Aeroquip by Danfoss
FC6646-0606S
This product has been discontinued and is no longer available. At this time, there is no direct replacement product.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
FC6646-0606S
Product specifications
Characteristic | Value | Description |
|---|---|---|
| Angle (shape) | Straight | |
| Brand | Aeroquip by Danfoss | |
| Compatible hose ID | .375 in | |
| Compatible hoses | 1503 | |
| Construction style | Crimp | |
| End gender 1 | Male | |
| End Size 1 | 5/8 IN | |
| End type 1 | SAE | |
| End type 2 | Line/Hose/Tube | |
| Feature | Dura-Kote plating for superior corrosion resistanceInnovative design to deliver performance and maximum uptimeSystem engineered to extend hose assembly life | |
| Finish/plating | Dura-Kote | |
| Hex Size 1 | .5 in | |
| Hex Size 2 | .625 in | |
| Hose dash size | -6 | |
| Inside diameter | .24 in | |
| Item type | Nipple | |
| Packaged Weight | .09 lb | |
| Product Height | .72 in | |
| Product Length/Depth | 3.06 in | |
| Product material | Carbon Steel | |
| Product Type | Crimp Hose Fittings | |
| Product Volume | 1.377 in³ | |
| Product Weight | .09 lb | |
| Product Width | .625 in | |
| Sub-brand | None | |
| Thread sealant | No | |
| Thread Size 1 | 5/8-18 | |
| Trade Name | FC6646 Series |
