Hose Fittings FBM1355 [RIGHT]

Aeroquip Performance by Danfoss

FCM1360

The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
Tools

Product specifications

Characteristic
Value
Angle (shape)90 Degree
BrandAeroquip Performance by Danfoss
Compatible hose ID.75 in
Compatible hosesFBA
Construction styleReusable
Drop dimension2.17
End gender 1Male
End Size 11 1/16 IN
End type 1UNF
End type 2Line/Hose/Tube
FeatureSystem engineered to extend hose assembly lifeHigh performance to increase uptime in critical operationsSuperior durability made to last
Finish/platingRed Anodized
Hex Size 11.25 in
Hex Size 21.1875 in
Hose cut-off factor2.2 in
Hose dash size-12
Inside diameter.59 in
Item typeFitting Assembly
Outside diameter1.25 in
Packaged Height6.5 in
Packaged Length9 in
Packaged Volume819 in³
Packaged Weight1.34 lb
Packaged Width14 in
Product Height2.79 in
Product Length/Depth3.84 in
Product materialAluminum
Product TypeReusable Hose Fittings
Product Volume13.392 in³
Product Weight.34 lb
Product Width1.25 in
Sub-brandNone
Thread sealantNo
Thread Size 11 1/16-12
Trade NameNone
UPC678146012364
