Aeroquip by Danfoss
FJ4649-1620S
This product has been discontinued.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
FJ4649-1620S
Product specifications
Characteristic | Value | Description |
|---|---|---|
| Angle (shape) | Straight | |
| Brand | Aeroquip by Danfoss | |
| Compatible hose ID | 1.25 in | |
| Compatible hoses | 1503 | |
| Construction style | Reusable | |
| End gender 2 | Male | |
| End Size 2 | 1 5/16 IN | |
| End type 1 | Flanged | |
| End type 2 | SAE | |
| Feature | Fit for wide range of applicationsDurable and dependableCut assembly times and boost production | |
| Finish/plating | DURA-KOTE | |
| Hex Size 1 | 1.38 in | |
| Hose cut-off factor | 1.56 in | |
| Hose dash size | -20 | |
| Inside diameter | 1.05 in | |
| Item type | Nipple Assembly | |
| Packaged Height | 14 in | |
| Packaged Length | 7 in | |
| Packaged Volume | 882 in³ | |
| Packaged Weight | .8 lb | |
| Packaged Width | 9 in | |
| Product Diameter | 2.03 in | |
| Product Height | 2.03 in | |
| Product Length/Depth | 3.31 in | |
| Product material | Carbon Steel | |
| Product Type | Reusable Hose Fittings | |
| Product Volume | 13.64 in³ | |
| Product Weight | .58 lb | |
| Product Width | 2.03 in | |
| Sub-brand | None | |
| Thread sealant | No | |
| Thread Size 2 | 1 5/16-18 | |
| Trade Name | FJ4629 Series | |
| UPC | 678146065773 |
