Boston by Danfoss
H198206RD-75RG
This product has been discontinued and is no longer available. At this time, there is no direct replacement product.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
H198206RD-75RG
Product specifications
Characteristic | Value | Description |
|---|---|---|
| Abrasion resistance | Standard | |
| Application | Air multi purpose. | |
| Bend radius - min | 20 in | |
| Brand | Boston by Danfoss | |
| Burst pressure | 1200 Psi | |
| Color | Red | |
| Conductivity | Non-Conductive | |
| Construction | 4 Spiral | |
| Cover material | Synthetic Rubber | |
| Cover style | Pin-Pricked | |
| Dash size | -6 | |
| Feature | A solution for every hose needIndustry leader since 1870Designed for safety and reliability | |
| Inside diameter | .38 in | |
| Lay line style | Ink Jet | |
| Outside diameter | .75 in | |
| Package form | Reel | |
| Packaged Weight | 13.5 lb | |
| Product Height | .75 in | |
| Product Length/Depth | 75 ft | |
| Product Type | Industrial Hose | |
| Product Volume | 506.25 in³ | |
| Product Weight | 13.5 lb | |
| Product Width | .75 in | |
| Qualified hose fittings | U Series, Z Series, 1A, Boss, Ground joint, Air hammer, Air king, quick disconnect | |
| Reinforcement material | Textile | |
| Sub-brand | None | |
| Trade Name | Marathoner | |
| Tube material | Synthetic Rubber | |
| Tube wall thickness | .185 in | |
| UPC | 639789340276 | |
| Working pressure | 300 Psi | |
| Working temperature - max | 180 °F | |
| Working temperature - min | -40 °F |
