Product specifications
Characteristic | Value |
|---|---|
| PRODUCT | VAR DISP OCP PVM PUMP |
| DISPLACEMENT | 98.3 CM3/R[6.00 IN3/R] 280 BAR |
| VALVE PLATE | IND (1800 RPM MAX) |
| INPUT ROTATION | CW (RH) SHAFT ROTATION |
| INPUT SHAFT | SAE J744-32-1 SAE C STR KY |
| Mounting Flange | SAE J744-127-4 C4B |
| MAIN PORT LOCATION | SIDE |
| PORT OPTIONS | SAE J518 FP SAE AP |
| PUMP SPECIAL FEATURES | AMDS (CONTAIN SSS) |
| CONTROL | PC |
| PRESSURE COMP SET | 276-284 BAR[4002-4118 LBF/IN2] |
| FLOW COMP UNLD VLV RPC SET | NONE |
| UNLD VLV TQ CONTROL SET | NONE |
| COMP SPECIAL FEATURES | NONE |
| AUXILIARY MOUNTING | SAE C 2/4B 14T SPL |
| Paint | BLACK [DEFAULT] |
| Customer identification | None |
| DESIGN CODE | A |
| Brand | Vickers by Danfoss |
