Product specifications
Characteristic | Value |
|---|---|
| PRODUCT | VAR DISP OCP PVM PUMP |
| DISPLACEMENT | 21.1 CM3/R[1.29 IN3/R] 230 BAR |
| VALVE PLATE | MOBILE (2800 RPM MAX) |
| INPUT ROTATION | CW (RH) SHAFT ROTATION |
| INPUT SHAFT | SAE J744-16-4 SAE A 9T SPL |
| Mounting Flange | SAE J744-82-2 C2B |
| MAIN PORT LOCATION | END |
| PORT OPTIONS | SAE J514 TP SAE AP |
| PUMP SPECIAL FEATURES | AMDS (CONTAIN SSS) |
| CONTROL | PC |
| PRESSURE COMP SET | 227-234 BAR[3277-3393 LBF/IN2] |
| FLOW COMP UNLD VLV RPC SET | NONE |
| UNLD VLV TQ CONTROL SET | NONE |
| COMP SPECIAL FEATURES | NONE |
| AUXILIARY MOUNTING | NONE (RP ONLY) |
| Paint | BLACK [DEFAULT] |
| Customer identification | None |
| DESIGN CODE | A |
| Brand | Vickers by Danfoss |
