Product specifications
Characteristic | Value |
|---|---|
| Additional ports | None |
| Brand | Danfoss |
| Cylinder relief valve setting | None |
| Design code | 5 |
| Displacement | 983 cm3/r [60.0 in3/r] |
| Flow amplification | None |
| Fluid type | Per Danfoss bulletin 3-401 |
| Identification | Danfoss number on nameplate |
| Inlet or LS relief setting | None |
| Inlet pressure rating | 241 bar [3500 PSI] |
| Input torque | Standard |
| Load circuit | Non reaction |
| Mounting threads | 4X .375-16 ON MOUNTING FACE |
| Neutral circuit | Closed center |
| Nominal flow rating | 95 LPM [25.00 GPM] |
| P,t,l, and r port size | 1.0625-12 UN SAE O-RING PORT |
| Paint and packaging | Black paint |
| Product series | Series 25 |
| Return pressure rating | 10 bar [145 PSI] MAXIMUM |
| Special application options | None |
| Special application options | None |
| Valve options | None |
