Product specifications
Characteristic | Value |
|---|---|
| Additonal Ports | NONE |
| Brand | Danfoss |
| Cylinder Relief Valve Setting | None |
| Design code | 3rd Design |
| Displacement | 31.5 cm3/r [1.92 in3/r] |
| Flow Amplification | None |
| Fluid Type | Reference bulletin 3-401 |
| Identification | EATON PRODUCT NUMBER ON NAMEPLATE |
| Inlet or LS relief setting | None |
| Inlet Pressure Rating | 140 BAR [2030 PSI] |
| Input Torque | Standard |
| Load Circuit | Non reaction |
| Mechanical Interface | INTERNAL INVOLUTE SPLINE 12 TOOTH 16/32 DP30 DEGREE PA |
| Mounting Threads | NONE ON PORT FACE 4X M10 x 1.5-6H ONMOUNTING FACE |
| Neutral Circuit | Closed center |
| Nominal Flow Rating | 11 LPM [3.00 GPM] |
| P,T,L, AND R PORT SIZE | SIDE PORTED 4X .5625-18 UNF-2B SAE O-RING PORT |
| PAINTS & PACKAGING | BLACK PAINT |
| Product height in | 3.170 |
| Product height mm | 80.518 |
| Product length in | 5.320 |
| Product length mm | 135.128 |
| Product series | Series 5 Steering Unit |
| Product width in | 3.170 |
| Product width mm | 80.518 |
| Return Pressure Rating | 10 BAR [145 PSI] |
| Special Application Options | None |
| Special Features | SEALED STAR |
| Valve Options | Manual steering check valve |
