Product specifications
Characteristic | Value |
|---|---|
| Angle shape | 90 Degree |
| Brand | Danfoss |
| Drop dimension IN | 0.940 |
| Drop dimension MM | 23.90 |
| End Type 1 | Line/hose/tube |
| End Type 2 | Line/hose/tube |
| Hex size 1 IN | 0.560 |
| Hex size 1 MM | 14.200 |
| Thread sealant | No |
| Tube outside diameter 1 IN | 0.340 |
| Tube outside diameter 1 MM | 8.600 |
| Tube outside diameter 2 IN | 0.340 |
| Tube outside diameter 2 MM | 8.600 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 757522302012 |
