Product specifications
Characteristic | Value |
|---|---|
| Brand | Danfoss |
| Drop dimension IN | 1.940 |
| Drop dimension MM | 49.30 |
| End type 1 | Male 37 degree |
| End type 2 | Male 37 degree |
| Finish plating | Dura-Kote |
| Hex size 1 IN | 1.250 |
| Hex size 1 MM | 31.800 |
| Hex size 2 IN | 1.250 |
| Hex size 2 MM | 31.800 |
| Item type | Adapter-tee |
| Product material | Carbon steel |
| Thread sealant | No |
| Thread size 1 | 1 1/16-12 UN |
| Thread size 2 | 1 1/16-12 UN |
| Thread size 3 | 1 1/16-12 UN |
| Tube outside diameter 1 IN | 0.750 |
| Tube outside diameter 1 MM | 19.100 |
| Tube outside diameter 2 IN | 0.750 |
| Tube outside diameter 2 MM | 19.100 |
| Tube outside diameter 3 IN | 0.750 |
| Tube outside diameter 3 MM | 19.100 |
| Working pressure bar | 207.00 |
| Working pressure psi | 3000.00 |
| Working temp max C | 121 |
| Working temp max F | 250 |
| Working temp min C | -40 |
| Working temp min F | -40 |
