Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 4.650 |
| A dimension MM | 118.100 |
| Angle shape | 45 Degree |
| Compatible hose ID IN | 0.620 |
| Construction Style | Reusable |
| Drop dimension IN | 1.000 |
| Drop dimension MM | 37.00 |
| End Type 1 | Male o'ring pilot rigid short |
| End size 1 | -10 |
| Hex size 1 IN | 0.875 |
| Hex size 1 MM | 22.225 |
| Hose cut off factor IN | 3.100 |
| Hose cut off factor MM | 78.700 |
| Inside diameter IN | 0.3700 |
| Inside diameter MM | 9.5000 |
| Product height in | 2.060 |
| Product height mm | 52.324 |
| Product length in | 4.850 |
| Product length mm | 123.190 |
| Product width in | 0.880 |
| Product width mm | 22.352 mm |
| Seal material | Hydrogenated Nitrile (HNBR) |
| Thread sealant | No |
| Working temperature max C | 125 |
| Working temperature max F | 257 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 678146013378 |
