Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.878 |
| A dimension MM | 73.100 |
| Angle shape | Straight |
| Brand | Danfoss |
| Compatible hose ID IN | 0.500 |
| Compatible hose ID MM | 12.700 |
| Compatible hoses | GH134 |
| Construction Style | Reusable |
| End Type 1 | Tube-O female long pilot |
| End Type 2 | Line/hose/tube |
| End size 1 | -8 |
| Finish plating | Dura-Kote |
| Hex size 1 IN | 0.866 |
| Hex size 1 MM | 22.000 |
| Hex size 2 IN | 0.866 |
| Hex size 2 MM | 21.996 |
| Hose cut off factor IN | 1.335 |
| Hose cut off factor MM | 33.900 |
| Hose size | -8 |
| Inside diameter IN | 0.315 |
| Inside diameter MM | 8.000 |
| Product height in | 0.866 |
| Product height mm | 21.996 |
| Product length in | 3.263 |
| Product length mm | 82.880 |
| Product material | Carbon steel |
| Product width in | 0.866 |
| Product width mm | 21.996 mm |
| Thread sealant | No |
| Thread size 1 | 3/4-16 UNF |
| Working temperature max C | 125 |
| Working temperature max F | 257 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
