Product specifications

Characteristic
Value
A dimension IN5.580
A dimension MM141.800
Angle shapeStraight
BrandDanfoss
Compatible hose ID IN0.500
Compatible hose ID MM12.700
Compatible hosesGH134
Construction StyleReusable
End size 1-8
Finish platingDura-Kote
Hose cut off factor IN2.500
Hose cut off factor MM63.400
Hose size-8
Inside diameter IN0.310
Inside diameter MM8.000
Product height in0.622
Product height mm15.801
Product length in4.953
Product length mm125.801
Product materialCarbon steel
Product width in0.622
Product width mm15.801 mm
Thread sealantNo
Working temperature max C125
Working temperature max F257
Working temperature min C-40
Working temperature min F-40
