Product specifications

Characteristic
Value
A dimension IN5.500
A dimension MM139.600
Angle shapeStraight
BrandDanfoss
Compatible hose ID IN0.500
Compatible hose ID MM12.700
Construction StyleReusable
End size 1-8
Finish platingZinc plating
Hose cut off factor IN2.410
Hose cut off factor MM61.200
Hose size-8
Inside diameter IN0.310
Inside diameter MM8.000
Product height in2.710
Product height mm68.800
Product length in5.500
Product length mm139.600
Product materialCarbon steel
Product width in0.866
Product width mm22.000 mm
Seal materialHydrogenated Nitrile (HNBR)
Thread sealantNo
Working temperature max C125
Working temperature max F257
Working temperature min C-40
Working temperature min F-40
