Product specifications

Characteristic
Value
A dimension IN3.780
A dimension MM95.900
Angle shapeStraight
BrandDanfoss
Compatible hose ID IN1.000
Compatible hose ID MM25.400
Compatible hosesFC800
Construction StyleReusable
End size 1-16
Finish platingZinc plating
Hex size 1 IN1.180
Hex size 1 MM29.972
Hex size 2 IN1.181
Hex size 2 MM30.000
Hose cut off factor IN2.610
Hose cut off factor MM66.400
Hose size-16
Inside diameter IN0.690
Inside diameter MM17.500
Product height in3.360
Product height mm85.344
Product length in3.780
Product length mm96.012
Product materialCarbon steel
Product width in1.970
Product width mm50.038 mm
Seal materialHydrogenated Nitrile (HNBR)
Thread sealantNo
Working temperature max C125
Working temperature max F257
Working temperature min C-40
Working temperature min F-40

General specifications

Characteristic
Value
EAN/UPC678146194145
