Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.820 |
| A dimension MM | 46.220 |
| Angle shape | Straight |
| Compatible hose ID IN | 0.380 |
| Compatible hose ID MM | 9.500 |
| Construction Style | Crimp |
| End size 1 | -6 |
| End type 1 | Flareless Tube Ermeto |
| Finish plating | Zinc plating |
| Hex size 1 MM | 17.000 |
| Hex size 2 IN | 0.625 |
| Hex size 2 MM | 16.000 |
| Hose cut off factor IN | 0.880 |
| Hose cut off factor MM | 22.350 |
| Hose size | -6 |
| Inside diameter IN | 0.2810 |
| Inside diameter MM | 7.1300 |
| Product material | Carbon steel |
| Series | E Series |
| Thread size 1 | 9/16-18 UNF |
| Working temperature max C | 150 |
| Working temperature max F | 302 |
| Working temperature min C | -48 |
| Working temperature min F | -55 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 725975721704 |
