Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.130 |
| A dimension MM | 54.102 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.620 |
| Construction Style | Reusable |
| End size 1 | -8 |
| End type 1 | Male pipe (NPTF) |
| Hex size 2 IN | 1.000 |
| Hex size 2 MM | 25.400 |
| Hose cut off factor IN | 0.900 |
| Hose cut off factor MM | 22.900 |
| Inside diameter IN | 0.470 |
| Inside diameter MM | 11.938 |
| Product height in | 1.000 |
| Product height mm | 25.400 |
| Product length in | 2.130 |
| Product length mm | 54.102 |
| Product material | Brass |
| Product width in | 1.000 |
| Product width mm | 25.400 mm |
| Reusable socket hex MM | 25.400 |
| Thread sealant | Yes |
| Thread size 1 | 1/2-14 NPTF |
| Working temperature max C | 260 |
| Working temperature max F | 500 |
| Working temperature min C | -73 |
| Working temperature min F | -100 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 678146031365 |
