Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.550 |
| A dimension MM | 39.500 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.380 |
| Compatible hose ID MM | 9.525 |
| Compatible hoses | 2807 |
| Construction Style | Reusable |
| End size 1 | -4 |
| End type 1 | Male pipe (NPTF) |
| End type 2 | Line/hose/tube |
| Finish plating | Passivate |
| Hex size 1 IN | 0.688 |
| Hex size 1 MM | 17.5 |
| Hex size 2 IN | 0.688 |
| Hex size 2 MM | 17.5 |
| Hose cut off factor IN | 0.649 |
| Hose cut off factor MM | 16.500 |
| Hose size | -6 |
| Inside diameter IN | 0.276 |
| Inside diameter MM | 7.000 |
| Product height in | 0.687 |
| Product height mm | 17.450 |
| Product length in | 1.555 |
| Product length mm | 39.497 |
| Product material | 304 Stainless steel |
| Product width in | 0.687 |
| Product width mm | 17.449 mm |
| Thread sealant | Yes |
| Thread size 1 | 1/4-18 NPTF |
| Working pressure max bar | 655 |
| Working pressure max psi | 9100 |
| Working temperature max C | 260 |
| Working temperature max F | 500 |
| Working temperature min C | -73 |
| Working temperature min F | -100 |
