Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.937 |
| A dimension MM | 74.600 |
| Angle shape | Straight |
| Compatible hose ID IN | 1.000 |
| Compatible hose ID MM | 25.400 |
| Construction Style | Crimp |
| End size 1 | -16 |
| End Type 1 | Male pipe (NPTF) |
| Finish plating | None |
| Hex size 2 IN | 1.375 |
| Hex size 2 MM | 34.925 |
| Hose cut off factor IN | 1.844 |
| Hose cut off factor MM | 46.840 |
| Hose size | -16 |
| Inside diameter IN | 0.817 |
| Inside diameter MM | 20.750 |
| Product material | Brass |
| Thread size 1 | 1-11 1/2 NPTF |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 810075330601 |
